Adjustable Speed Lane Automatic Flap Barrier Gate Entry Turnstiles

Brand Name : WEJOIN

Model Number : WJTY202

Certification : ISO

Place of Origin : China

MOQ : 1set

Price : Negotiation

Payment Terms : T/T

Supply Ability : 3000 SETS

Delivery Time : 3-7DAYS

Packaging Details : WOODEN

Housing Finished : Stainless Steel

Flap Speed : Adjustable

Flap Material : Oganic Glass

Infrared Photocell : Yes

Security Gate : Yes

Working Temperature : -25°C ~ 50°C

Input Interface : Dry contact signal

Running Time : 0.5s

Contact Now

Adjustable Speed Lane Automatic Flap Barrier Gate Entry Turnstiles

Flap Turnstile Description:

Intelligence flap barrier (block gate) is product with intelligent management of high-tech mainly for staff access. Flap barrier is upgrade of intelligent tripod turnstiles and swing gates.The product with precision processed, complete function and high quality, mainly used in high-end residential, intelligent buildings, hotels, subway, pier, clubs and other places.
The flap barrier organically integrated mechanism, electronic, microprocessor control and a variety of identification technologies. It's easy to integrated IC card, ID card, bar code platform, fingerprint, facial recognition and other devices. It could coordinated realize intelligent controls and management for channel by matching various identification system equipment and the using reliable security devices, alarm devices and direction indication.

Function &Feature:

1. Anti-breakthrough function. The gate is locked automatically until opening signal received

2. Automatic reset function. Should the user fail to pass within the prescribed time (default time is 5 seconds),the system will cancel the authority of the current user automatically.

3. Can be used with variety of card readers: IC / ID card readers, bar codes, fingerprints, etc.

(Access controller needed)

4. Direction can be set as single-direction or bi-direction.

5. LED direction indicator.

6. Gate auto opens when power off and auto close when power on, complying with fire safety requirements.

7. Alarm function, in case of illegal intrusion and reverse intrusion, etc.

8. Counter function (optional).

9. Support infrared photocell for anti-pinch and reset function (optional).

Specifications:

Model WJTY202
Stretching-out flap length 275mm
The max lane width 600mm
Cabinet material Cold rolled steel & aluminum alloy
Material of Flap Door Organic glass
Housing of thickness 1.5mm
Normal Life Span 3 millions times
Communication Interface Standard RS485(distance less than 1200 meters)
Transit speed 30-40 persons/min
Time for opening or closing 0.5s
Starting time after power on 3s
Input interface Dry contact signal or +12Vor pulse signal with width more than100ms DC12V
Transit speed 25~32 persons/min
Working temperature -10°C~50°C
Working environment Indoor / Outdoor (Shelter)
Relative humidity ≤95%, no condensation
